AIOMEST Digital Anemometer AI-816B User Manual

1. Giới thiệu

The AIOMEST Digital Anemometer AI-816B is a compact, handheld device designed for measuring wind speed and temperature. It features sensitive fan blades for accurate readings, a backlit LCD display for clear visibility, and multiple unit options for versatility. This manual provides detailed instructions for the proper use and maintenance of your anemometer.

2. Thông tin an toàn

Không để thiết bị ở nơi có nhiệt độ quá cao hoặc tiếp xúc trực tiếp với ánh nắng mặt trời trong thời gian dài.
Tránh làm rơi thiết bị hoặc để thiết bị chịu tác động mạnh.
Tránh để thiết bị tiếp xúc với nước và độ ẩm cao để ngăn ngừa hư hỏng.
Đảm bảo phân cực pin chính xác trong quá trình cài đặt.
Không được tự ý tháo rời hoặc sửa đổi thiết bị, vì điều này sẽ làm mất hiệu lực bảo hành.

3. Sản phẩm hếtview

3.1 Các tính năng chính

7 Sensitive Fan Blades for precise wind measurement.
Measures wind velocity and temperature.
Features Max/Average/Current mode.
Wind chill indication.
Backlit LCD display for clear readings.
5 airflow velocity units: m/s, ft/min, knots, km/hr, mph.
Temperature units: Fahrenheit/Celsius switchable.
Tự động tắt để tiết kiệm pin.
Thiết kế nhỏ gọn và nhẹ.

3.2 Thành phần thiết bị

AIOMEST Digital Anemometer AI-816B showing its features: Temperature, Back Light, C/F Switch, Wind Speed Units Selection, Wind Chill Indicator, Real Time Measurement, Wind Speed Measurement, Auto Power OFF. — Figure 1: AIOMEST Digital Anemometer AI-816B with key features labeled.

The image above illustrates the main features of the AIOMEST AI-816B anemometer, including its ability to measure temperature, provide backlight, switch between Celsius and Fahrenheit, select wind speed units, indicate wind chill, offer real-time measurements, and automatically power off.

AIOMEST Digital Anemometer AI-816B with dimensions and button functions. The device measures 113mm/4.4 inches in length, 40mm/1.7 inches in width, and 15mm/0.5 inches in thickness. Buttons are labeled MODE, °C/°F, and SET. — Figure 2: Dimensions and button layout of the AIOMEST AI-816B anemometer.

This image provides a visual guide to the physical dimensions of the anemometer and highlights the functions of its three control buttons: MODE, °C/°F, and SET. The MODE button is used for selection and backlight, the °C/°F button switches temperature units, and the SET button is for mode options and power off.

4. Thiết lập

4.1 Lắp đặt pin

The AIOMEST AI-816B anemometer uses one CR2032 3.0V battery. Follow these steps to install or replace the battery:

Use a coin to rotate the battery cover counter-clockwise to the "OPEN" position.
Cẩn thận tháo nắp pin.
Insert the CR2032 battery with the positive (+) side facing up, ensuring correct polarity.
Place the battery cover back and rotate it clockwise to the "CLOSE" position using a coin.

Steps for replacing the battery in the AIOMEST Digital Anemometer AI-816B. Shows using a coin to open the battery cover, inserting the CR2032 battery with positive side up, and closing the cover. — Figure 3: Battery replacement procedure for the AI-816B.

This image visually guides you through the process of replacing the CR2032 battery, from opening the cover with a coin to correctly inserting the new battery and securing the cover.

4.2 Bộ phận gắn dây đeo

To attach the included lanyard for convenient carrying:

Locate the small loop hole on the top side of the anemometer.
Thread the thin loop end of the lanyard through this hole.
Pass the main strap of the lanyard through the loop you just created and pull tight to secure.

AIOMEST Digital Anemometer AI-816B with its lanyard attached, showing the device's display and battery compartment. — Figure 4: AI-816B anemometer with attached lanyard.

The image displays the anemometer with its lanyard properly attached, ready for portable use.

4.3 Hướng dẫn cài đặt bằng video

Video 1: This video demonstrates the battery installation and basic key usage for the AIOMEST AI-816B anemometer, including how to attach the lanyard.

5. Hướng dẫn vận hành

5.1 Bật/Tắt nguồn

Bật nguồn: Long press the "MODE" button to turn on the device. The display will show "m/s" flashing.
Tắt nguồn: Long press the "SET" button to manually turn off the device. The device will also automatically shut off after 5 seconds (or 12 minutes, depending on the specific model's firmware) of inactivity to conserve battery.

5.2 Mode and Unit Selection

Temperature Unit Switch (°C/°F): Nhấn nút "°C/°F" để chuyển đổi giữa độ C và độ F.
Wind Speed Unit Selection: While the device is on, short press the "MODE" button to cycle through the available wind speed units: m/s, ft/min, knots, km/hr, and mph.
Chế độ đo: The device supports Max, Average, and Current wind speed readings. Use the "MODE" button to switch between these display modes.

5.3 Đèn nền

To activate the backlight for improved visibility in low-light conditions, short press the "MODE" button. The backlight will remain on for a short period.

5.4 Wind Chill Indication

The anemometer provides a wind chill indication, especially useful in colder environments. Refer to the display for this reading.

5.5 Measuring Wind Speed

Hold the anemometer upright, ensuring the fan blades are exposed to the wind flow. The display will show real-time wind speed and temperature readings. For accurate measurements, ensure no obstructions are blocking the fan.

A hand holding the AIOMEST Digital Anemometer AI-816B, showing a wind speed reading of 36.7 km/h and a temperature of 23.2°C on its backlit display. — Figure 5: Anemometer in use, displaying wind speed and temperature.

This image shows the anemometer being held, demonstrating how to read the wind speed and temperature from its display during operation.

5.6 Các tình huống ứng dụng

Various application scenarios for the AIOMEST Digital Anemometer AI-816B, including surfing, shooting, kite flying, drone operation, checking vents, and monitoring windmills. — Figure 6: Diverse applications of the AI-816B anemometer.

The image illustrates the versatility of the AIOMEST AI-816B, showing its utility in activities like surfing, shooting, kite flying, drone piloting, HVAC system checks, and wind turbine monitoring.

6. Bảo trì

6.1 Vệ sinh

Wipe the device with a soft, dry cloth. Do not use abrasive cleaners or solvents. Ensure the fan blades are free from dust and debris for accurate readings.

6.2 Lưu trữ

When not in use for extended periods, remove the battery to prevent leakage. Store the device in a cool, dry place away from direct sunlight.

KHAI THÁC. Xử lý sự cố

Thiết bị không bật: Kiểm tra xem pin đã được lắp đúng cách và có đủ điện tích chưa. Thay pin nếu cần thiết.
Số đọc không chính xác: Ensure the fan blades are clean and unobstructed. Verify that the device is held correctly in the wind path.
Sự cố hiển thị: If the display is dim or flickering, the battery may be low. Replace the battery.

8. Thông số kỹ thuật

Tính năng	Chi tiết
Người mẫu	AI-816B
Phạm vi tốc độ gió	0-65 mph (0.2 resolution)
Độ chính xác của tốc độ gió	±5%
Phạm vi nhiệt độ	14 ~ 113 ° F (-10 ~ 45 ° C)
Nguồn điện	CR2032 3.0V battery (1pc)
Kích thước	4.88 x 2.13 x 1.54 inch (khoảng 12.4 x 5.4 x 3.9 cm)
Trọng lượng sản phẩm	1.76 ounce (khoảng 50g)
Vật liệu	Nhựa
Tự động tắt	After 5 seconds of inactivity (some models may be 12 minutes)

9. Bảo hành và Hỗ trợ

The AIOMEST Digital Anemometer AI-816B comes with a 12-month product warranty and lifetime technical support. If you encounter any issues or have questions regarding your device, please contact AIOMEST customer service for assistance.

For support, please visit the official AIOMEST webVui lòng truy cập trang web hoặc tham khảo thông tin liên hệ được cung cấp kèm theo đơn hàng của bạn.
